Materials: 316L stainless steel, PPS, Rulon special engineering materials
Working Pressure: 3-22 bar
Cleaning Fluid: Water, weak acid solution, weak base solution
Recommended Pressure: 4-20 bar
Maximum Operating Temperature: 95°C
Maximum Ambient Temperature: 120°C
Cleaning Angle: 180°
Cleaning Diameter: 30m
Connection Specifications: 2" BSPT/NPT Female Thread or 2-1/2" Quick Disconnect
Tanker Opening: ≥ 300mm
Cleaning Cycle: 10-30 minutes
Weight: 13kg
Features:
1. 180° Cleaning without Dead Angles
When the cleaner is operating, liquid pressure drives the X and Y axes to rotate simultaneously. The high-impact water jet creates a three-dimensional circular motion within 180 degrees of the tank wall, forming a dense grid on the tank wall for clean, angle-free cleaning, as shown in the spherical tank illustration.
2. Sealing: Dynamic sealing is used at leak points to reduce leakage, conserve cleaning fluid, and generate greater water flow force.
3. Higher Impact Force
The nozzle's unique steady-flow design ensures a more concentrated water jet, greater impact, and more thorough cleaning.
Industry Applications:
1. Pharmaceutical Industry
Applicable Equipment: Reactors, liquid mixing tanks, fermentation tanks, intermediate storage tanks, etc.
2. Food and Beverage Industry
Applicable Equipment: Syrup tanks, beverage mixing tanks, seasoning tanks, milk storage tanks, jam jars, etc.
3. Chemical Coatings Industry
Applicable Equipment: Emulsification tanks, reactors, liquid storage tanks, mixing tanks, etc.
4. Bio-fermentation Industry
Applicable Equipment: Large and medium-sized fermentation tanks, seed tanks, culture tanks, etc.
5. Alcohol and Dairy Industry
Applicable Equipment: Brewing tanks, milk storage tanks, fermentation tanks, sake tanks, etc.
6. Hazardous Waste and Environmental Protection Industry
Applicable Equipment: Oil storage tanks, septic tanks, hazardous waste temporary storage tanks, waste liquid barrels, etc.
7. Other Industries Requiring Tank and Container Cleaning Products, Such as Papermaking, etc.
