Material: 316L stainless steel, PEEK, EPDM
Operating Pressure: 2-30 bar
Cleaning Fluid: Water, weak acid solution, weak alkaline solution
Recommended Pressure: 5-20 bar
Maximum Operating Temperature: 100°C
Maximum Ambient Temperature: 120°C
Cleaning Angle: 360°
Cleaning Diameter: 2.5m
Connection Size: G3/4
Tank Opening: ≥φ45mm
Cleaning Cycle: 10-30 minutes
Weight: 2.0 kg
Product Features:
360° Full Coverage Cleaning
During operation, the liquid pressure drives the impeller to rotate, which in turn drives the internal reduction mechanism. The drive mechanism then rotates the X and Y axes simultaneously along a predetermined path, achieving 360° full coverage cleaning.
Sealing Performance
A dynamic seal is used at the potential leak points to minimize leakage and conserve cleaning fluid. This also generates greater water flow impact.
Higher Impact Force
The nozzle features a unique flow-stabilizing design, concentrating the water stream for greater impact and more thorough cleaning.
