Design features
1. Working principle: The fine water flow is sheared by the high-speed airflow to form a preliminary atomization. The preliminary atomized water droplets are mixed with the high-speed airflow and hit the vibration head, and further atomized into extremely fine particles of water mist
2. The average particle size of the atomized water droplets is very small, and the maximum particle size is not much different from the minimum particle size, and the particle size is uniform
3. The vibration generated by the collision of the vibration head and the high-speed airflow can prevent dust or other foreign objects from adhering to the spray hole, ensuring the normal operation of the nozzle
4. The product is reliable and rarely requires maintenance
Features
1. The ultrasonic atomizing nozzle forms a circular striking area;
2. The droplet size is small to medium;
3. Under a pressure of 0.7 bar (10 psi), the reflection angles determined by the reflective cap are: 150° and 180°;
4. This linear nozzle has a lower cross-sectional projection when installed on a T-joint or a header, and is widely used for coal ash suppression.
Installation method
The ultrasonic atomizing nozzle provides several mounting bases suitable for different occasions to meet the needs of various users. There are ordinary bases, thin-walled mounting bases, universal ball mounting bases, and spray boxes.
